Amerec AI-12
AI Series 12kW Commercial Steam Room Generator
The 12kW Amerec AI-12 commercial steam shower generator is engineered for the most demanding commercial health club steam rooms with dimensions of up to 550 cubic feet (CF). The Amerec AI-series steam boilers include two 3/4" NPT steam heads. Required control sold separately.
See Shipping Tab
- Pressurized vessel for instant steam
- Durable electronic components
- Low water cut-off with manual reset
- 3/4” drain port
- Room high limit temperature safety system
- Operating, electronic high limit pressure control systems
- Sight glass
- Optional D24/7 digital time clock can be used for both generator on/off settings and ADI-D Autodrain system
- Alarm circuit panic button
- ASME safety valve
- ASME certified low-pressure operation vessel
- AI-12 steam boiler
- Two 3/4” NPT steam heads
- Installation and operation manual
- Limited warranty
| Model | AI-12 |
|---|---|
| Shipping Weight | 125 lbs |
| Minimum Adjusted Cubic Feet | 301 |
| Maximum Adjusted Cubic Feet | 550 |
| Kilowatt Rating | 12.0 KW |
| Electrical Specifications | Electrical Chart |
| Water Supply Connection | 1/2" NPT |
| Generator Steam Line Connection | 3/4" NPT |
| Steam Head Connection | 3/4" NPT |
| Drain Connection | 3/4" NPT |
| Safety Relief Valve Connection | 3/4" NPT |
| Safety Relief Valve | 15 PSIG |
| Control "Rough In" Cut Out | 2-1/8" x 3-1/4" |
| Control Sensor Cable | 25', 2 Conductor, 22 AWG, Shielded Cable |
| Control Sensor "Rough In" Cut Out | 7/8" Diameter |
| Generator Control Connection | 3 Position Terminal Block |
| Generator Control Cable | 25', 3 Conductor, 22 AWG, Shielded Cable |
| Width | 17-1/2" |
| Depth | 20-3/4" |
| Height | 23-1/4" |
The driver is responsible for curbside delivery “only” and will lower the items to ground level.
Prior to shipping this product, we contact customers to share shipment details and discuss any extenuating delivery circumstances that may complicate or cause additional delivery expenses.
Our goal is to ensure your project success.
With the Amerec IT1 Electronic Room Temperature control, set the desired steam room temperature and the boiler makes it happen.
As an option for operating any AI boiler, the Amerec D24/7 will start and stop at preset times (2-hour increments) throughout the week.
With the addition of the Amerec IT2 Electronic Room Temperature Control option, two rooms may be serviced by one AI boiler.
Supplied with all Amerec AI Series boilers, the CFSH-34 steam head has been designed to provide a safe and pleasurable steam bath experience.
Optional on all AI boilers, this electrically operated drain valve allows for automatic routine boiler draining.
Optional on all AI boilers, this electrically operated drain valve allows for automatic routine boiler draining.
When selected, this “Refresh” Switch option gives the bather a more immediate control over the steam room conditions.
Optional, and for use with all Amerec AI boilers the user activated, I60 60-Minute Electronic Timer mounts near the steam room for steam on/off 60-minute timer operation.
As an option for operating any AI boiler, the Amerec I24/7 will start and stop at preset times (2-hour increments) throughout the week.
As an option for operating the electronic autodrain blowdown valve, the I24/1 time clock allows for routine daily performance of the Amerec ADI Automatic Drain System.
