Delta 48kW Commercial Steam Boiler Package
DELTA® Commercial Steam Generator 48kW Package with Control & Steamhead
The 48kW Delta HC-48 Commercial Health Club Steam Room Generator comes with everything you need to get your steam room started. The generator is designed for round-the-clock operation for spaces up to 2,000 cubic feet! This package also features two controls for the ultimate management and client experiences. The digital command center allows management to program temperature ranges to account for idle and peak hours, the user bypass control allows clients to adjust steam output within the preset range, the room sensor provides accurate temperature readings to the generator, and steam head outputs the steam with 360-degree dispersion. We also offer a complete selection of accessories to comply with local codes or enhance your client’s experience. We cover our commercial products with a one-year warranty.
- Allows programming of steam room settings from up to 100' distance from generator (50' cables ship standard)
- Idle setback feature allows efficient tailoring of operations during off-peak hours. Each day of the week can be programmed individually. Provides maximum energy saving “idle” temperature
- When installed with second room package, two steam rooms can be programmed with one generator
- ASME code compliant
- UL listed
- The user bypass control should be installed outside the steam room to allow the user to change settings within programmed temperature range
- Steam Head 3/4" NPT, includes silicone cover
- Microprocessor boiler control with two relays prewired for the aromatherapy pump
- Digital command center with cable
- User bypass control with cable
- Room sensor with cable
- Steam solenoid pre-assembled to the steam generator
- Chrome transitional steam head
| Model | 5COM48-PAC-648-208-03 |
|---|---|
| Product dimensions | 39" L x 22" W x 28" H |
| Max Shower Volume | 2000 |
| Wattage | 48000 |
| Amperage | 133 |
| Phase | 3 |
| Line Fuse | 175 |
| PROP 65 Warning | Lead |
| Model | 5COM48-PAC-648-240-03 |
|---|---|
| Product dimensions | 39" L x 22" W x 28" H |
| Max Shower Volume | 2000 |
| Wattage | 48000 |
| Amperage | 116 |
| Phase | 3 |
| Line Fuse | 150 |
| PROP 65 Warning | Lead |
| Model | 5COM48-PAC-648-480-03 |
|---|---|
| Product dimensions | 39" L x 22" W x 28" H |
| Max Shower Volume | 2000 |
| Wattage | 48000 |
| Amperage | 58 |
| Phase | 3 |
| Line Fuse | 80 |
| PROP 65 Warning | Lead |
| Control | |
|---|---|
| Product Dimensions | 10-11/16"H x 3-1/8"D |
| Steam Head | |
|---|---|
| Product Dimensions | 3-3/16"H x 3-3/16"W x 1-1/4"D |
The weight or packaging of this product requires delivery by special appointment, and on a wooden pallet.
The driver is responsible for curbside delivery “only” and will lower the items to ground level.
Prior to shipping this product, we contact customers to share shipment details and discuss any extenuating delivery circumstances that may complicate or cause additional delivery expenses.
Our goal is to ensure your project's success
The Delta Generator Stand elevates the steam generator off the floor to a fair height providing comfort during transitions and maintenance repairs. Designed for use with the 5COM Series Generators, this stand is able to hold larger sized tanks.
The Delta Digital Auto Blowdown Valve creates an effective steam environment. This add-on to the 5COM Series Steam Generators automatically relieves trapped pressure at the end of your final use. Emptying the generator ensures quality and maximizes its life.
Blowdown for Boilers cannot be ordered standalone, they must be ordered with a boiler.
The automatic blowdown tempering valve installs into drain line as an alternative to a blowdown tank for tempering hot blowdown water. It injects cold tap water when thermal actuator senses blowdown water is over 120°F.
Many states and local jurisdictions, as a standard, require an independent, manual reset, second low water cut off control. This is a factory-installed option and cannot be sold without a 5COM Series Steam Generator.
Steam Generator Sold Separately
The commercial steam temperature alert is a must-have for safety. The lock feature prevents users from turning off the system or changing the temperature setpoint. The interrupt relay disables the heater when the audible alarm sounds and the test button is used to check that the heater is disabled when the alert sounds. The alert cannot be reset until the room cools below the programmed temperature.
A complete Steam Control Package for your second steam room. Includes additional user bypass control with 50' cable, room sensor with 50' cable, steam solenoid pre-assembled to the steam generator, and steam head.
Generator Required and Sold Separately
