Amerec AK11
AK Series 11KW Steam Shower Generator
The Amerec AK11 is an 11kW home steam shower generator engineered for residential and day spa steam baths up to 375 adjusted cubic feet (ACF).
Required control package sold separately.
- Sequential temperature control for consistent flow
- Stainless steel tank
- Industrial grade, serviceable heating elements
- Durable electronic components
- Electronic water-level control system
- Low voltage safety control circuits
- Available Auto Drain automatic draining system
- Ability to field wire in 1-phase or 3-phase
- Ability to connect multiple generators to heat steam baths larger than 550 cubic feet
- Operates with inside/outside shower, on/off, time/temperature controls
- Full 3/4" port drain valve
- ASME safety valve
- UL/CSA/CE listed
- 11kW steam bath generator
- Installation and operation manual
- Limited warranty
Model | AK11 |
---|---|
Minimum Adjusted Cubic Feet | 175 |
Maximum Adjusted Cubic Feet | 375 |
Kilowatt Rating (KW) | 11KW |
Shipping Weight (Lbs.) | 35 lbs |
AC Voltage | 240V AC |
DC Voltage | 5V DC |
Phase | Single Phase |
Nominal Amperage | 46 Amps |
Recommended Protective Device | 60 Amps |
Recommended Minimum Copper Wire Supply | 6 AWG |
Water Supply Connection | 3/8" NPT |
Generator Steam Line Connection | 1/2" NPT |
Steam Head Connection | 1/2" NPT |
Drain Connection | 3/4" NPT |
Safety Relief Valve Connection | 3/4" NPT |
Safety Relief Valve PSIG | 10 PSIG |
Control "Rough In" Cut Out | 2-3/8" Diameter |
Control Sensor Cable | 25', 2 Conductor, 22 AWG, Shielded Cable |
Control Sensor "Rough In" Cut Out | 7/8" Diameter |
Generator Control Connection | 8 Pin, Snap-In Connector |
Generator Control Cable | 25', 8 Conductor, 28 AWG, Shielded Cable |
Width In Inches | 16-1/2" |
Depth In Inches | 6-1/4" |
Height In Inches | 15" |
Glacier K2 Operating Equipment Package for AK Series Generators. Includes steam head.
Columbia K3 Operating Equipment Package for AK Series Generators. Includes steam head.
The Amerec K2 steam shower generator control kit works with Amerec AK series steam generators. Wi-Fi and Smart home ready, this control features adjustable time, temperature and a 24 hour delay and includes a ComfortFlo steam head.
6 different Trim Ring/Steam head finishes for the K2 control are available.
The Amerec K3 steam shower generator control kit works with Amerec AK series steam generators. This control kit is able to be mounted inside or outside the steam room and features a digital control, remote sensor and includes a ComfortFlo steam head.
6 different Steam head finishes for the K3 control kit are available.
The Amerec KT3 steam shower generator control kit works with Amerec AK series steam generators. A stylish update to Amerec's KT60 control, the control is backward compatible with the classic KT60. Featuring a built-in temperature sensor, this control was designed for use inside the steam room. With the simple ease of 3-buttons, you control on/off, temperature, and time duration settings. The display alternates every 5 seconds between atmospheric room temperature and the remaining time of your steam session. With maximum session settings of up to 125 °F and 60 minutes (residential use), this control kit includes a ComfortFlo steam head.
6 different Steam head finishes for the KT3 control kit are available.
The Amerec K4 steam shower generator control kit works with Amerec AK-series steam bath generators. This control kit may be mounted inside or outside the steam room and features a non-thermostatic control and includes a ComfortFlo steam head.
Choose from 6 available designer finishes for the ComfortFlo steam head.
