Steamist SMP-30
SM Plus Series 30kW Steam Bath Generator
ON SALE! The Steamist SMP-30 is a 30-kW steam shower generator engineered for large home steam baths and day spa steam rooms from 1101 to 1350 adjusted cubic feet (ACF). As a member of the Steamist Plus series generators, the Steamist SMP-30 provides homeowners with pleasant and consistent steam bathing experiences.
Required operating control sold separately.
- For steam baths sized from 1101 to 1350 adjusted cubic feet
- Available in 240V and 208V operation
- Stainless steel tank
- SteadySteam technology with 3-stage, industrial grade heating element
- Modular "snap-in" control connections
- Durable electronic components
- Electronic water-level control system
- Low voltage safety control circuits
- Solid-state circuitry
- Available Auto Drain automatic draining system
- Selectable InstaMist technology standard
- Optional tandem operation (up to 4 generators)
- Operates with inside/outside shower, on/off, time/temperature controls
- Diagnostic LED Displays
- Full port drain valve
- ASME safety valve
- UL 499
- UL/CUL Listed
- City of LA - Approved
- City of New York - M.E.A. Approved
- 30kW Steam bath generator
- 6-pin, 6-wire control cable, 35' long with snap-in connector
- Installation and operation manual
- Limited warranty
Model | SMP-30 |
---|---|
Minimum Adjusted Cubic Feet | 1101 |
Maximum Adjusted Cubic Feet | 1350 |
Shipping Weight (lbs) | 60 lbs. |
Kilowatt Rating (kW) | 30kW |
Water Supply Connection | 3/8" Compression Connection |
Generator Steam Line Connection | 3/4" NPT |
Steam Head Connection | 3/4" NPT |
Drain Connection | 1/2' NPT |
Safety Relief Valve Connection | 3/4' NPT |
Safety Relief Valve PSIG | 15 PSIG |
Control 'Rough In' Cut Out | 1-1/2" Diameter |
Generator Control Connection | 6-Pin, Snap-In Connector |
Generator Control Cable | 35', 6-Conductor, 22 AWG, Shielded Cable |
Width In Inches | 19" |
Depth In Inches | 11.25" |
Height In Inches | 17" |
The Steamist 550 is Steamist’s most advanced digital control system. Designed for use with all TSG or SM Plus steam generators, the Steamist 550 can operate with all Total Sense Spa options— AromaSense, ChromaSense, AudioSense, and ShowerSense.
The TSC-450 control is compatible with Steamist TSG and SM Plus steam generators, and can operate all Total Sense™ Spa Options.
Designed for use with the TSG or SMP steam generators, the Steamist 250 steam shower control package is programmable for two user settings of temperature and duration.
The Steamist 250 features an easy-to-read soft touch keypad, allowing bathers to easily navigate through settings. The Steamist 250 digital control system features the innovative dual-temperature sensor technology for superior temperature control.
