Mr.Steam SAH3000
Steam@Home Series 3kW Steam Shower Generator Package
On/off control and steam head included! The Mr Steam SAH3000 3kW home steam shower generator package is engineered for use in home steam baths with dimensions up to 75 adjusted cubic feet (ACF). Made in U.S.A.
SAH3000 Generator
- Unitized stainless steel reservoir
- Durable electronic components
- Electronic water-level control system
- Stainless steel design inside and out
- Low voltage safety control circuits
- Built in 24-volt circuit
- ASME safety valve
- Full port drain valve
- UL/CSA/CE listed
SteamStart Control
- On/Off operation
- 20-Minute run cycle non-adjustable
- Low profile
- Polished Chrome trim
- Inside/outside the steam/shower enclosure installation
- Low voltage operation
Cool-to-the-Touch Steamhead
- Quieter operation
- Integral reservoir for a scented steam bath
- Low profile and sleek design
- Polished Chrome finish
Acrylic Shield
- Clear Lexan construction, 1/8” thick, transparent look
- Measures 4-3/8" in diameter and is 1/2" deep
- Integral, 1-5/8” diameter mounting hole
- 3.0KW Steam bath generator
- SteamStart surface-mounted control, 1-1/2” diameter, 1/8” deep
- 3-Pin Control cable, 30’ long, hard-wired to control with plug-in connector
- Cool-to-the-Touch steamhead, 1/2” NPT, 3-1/16” diameter, 1-13/16” deep
- Acrylic shield, 4-3/8" diameter, 1/2" deep
- RTV silicone sealant, .5 ounce tube
- Installation and operation manual
- Limited warranty
| Model | SAH3000 |
|---|---|
| Maximum Adjusted Cubic Feet | 75 |
| Kilowatt Rating (KW) | 3.0 KW |
| Shipping Weight | 25 lbs |
| Electrical Specifications | (refer to Electrical chart) |
| Water Supply Connection | 3/8" NPT |
| Generator Steam Line Connection | 3/8" NPT |
| Steam Head Connection | 1/2" NPT |
| Drain Connection | 1/4" NPT |
| Safety Relief Valve Connection | 3/4" NPT |
| Safety Relief Valve PSIG | 15 PSIG |
| Control "Rough In" Cut Out | 7/8" Diameter |
| Generator Control Connection | 3-Pin, Plug-In Connector |
| Generator Control Cable | 30', 3 Conductor, 24 AWG, Shielded Cable |
| Width | 14-3/8" |
| Depth | 5-3/16" |
| Height | 14-7/8" |
| Adjustable Time | No |
| Session Timing | 20 minutes |
No need for frequent trips searching for those special plumbing fittings, Steam Sauna Living has carefully selected and packaged the brass and copper couplers, nipples, valves and unions for a simple, maintainable and serviceable steam generator installation. Use of these choice fittings will allow you to maximize your in-home, factory and labor warranties!
Award-winning and truly innovative, this Linear Steam Head for MS90–MSSUPER3 generators is the quietest of its kind. Installed flush with the wall, this Steam Head can be installed so only a slim opening remains visible.
